The LEEDAX 50 Watt LED Highbay Light Luminary is a compact, energy-efficient and high-performance industrial lighting solution designed for applications that require reliable illumination with controlled power consumption. With its optimized 50W system power, high lumen efficiency and uniform light distribution, this 50 Watt LED Highbay Light is particularly suitable for smaller factories, warehouses, workshops, assembly areas, storage facilities, retail spaces and commercial buildings.
Designed and manufactured by LEEDAX Lighting Technologies, the LXHBYLP50BX combines premium-quality LED technology, an efficient constant-current LED driver, precision reflector optics and a rugged aluminium pressure die-cast housing. This engineering approach enables the luminaire to provide dependable brightness, effective heat dissipation and a long operational life of up to 50,000 hours.
The 50W LED Highbay Light is designed for ceiling heights of approximately 4 to 7 metres, making it suitable for many industrial and commercial indoor lighting applications. Its 120° beam angle provides broad and uniform illumination, helping minimize dark spots and improve visibility across the working area.
Electrical efficiency is another important advantage. The luminaire offers driver efficiency above 85%, power factor greater than 0.95 and THD below 10%, supporting efficient utilization of electrical power. Integrated surge protection exceeding 6 KVA and over-voltage protection up to 440V AC provide additional electrical protection.
| Product Code | LXHBYLP50BX |
| System Power Consumption | 50 Watt |
| Surge Protection | > 6 KVA |
| Power Factor | > 0.95 |
| THD | < 10% |
| Colour Temperature | 3000K / 4000K / 6500K |
| Colour Rendering Index | > 80 CRI |
| Beam Angle | 120° |
| Operating Temperature | -10°C to +65°C |
| Input Voltage | 230V AC |
| Working Voltage Range | 145–270V AC |
| Over Voltage Protection | 440V AC |
| IP Rating | IP55 / IP65 (Optional) |
| LED Life | 50,000 Hours |
| LM-80 Report | Available |
| Driver Efficiency | >85% |
| Housing Material | Aluminium Pressure Die Cast |
| Cover | Toughened Glass |
| Applications | Industries, Warehouses, Workshops, Stores, Commercial Buildings |
| Manufacturer & Make | LEEDAX |
| Country of Origin | Made in INDIA |
| Tolerance | ±10% on all above values |
The LEEDAX 50 Watt LED Highbay Light is engineered with a combination of energy efficiency, optical performance, electrical protection and mechanical durability to meet the requirements of modern industrial and commercial lighting installations.
High Lumen Efficiency
The 50W LED Highbay Light is designed to provide excellent illumination while operating at only 50 watts, helping users achieve efficient lighting with controlled electricity consumption.
Superior Lux Distribution
Its precision-designed reflector optics and 120° beam angle provide broad and uniform illumination. This helps reduce dark areas and shadow formation across workspaces.
Energy-Efficient Operation
Compared with conventional industrial lighting technologies such as HID, Metal Halide and CFL systems, LED technology provides an efficient alternative with lower energy consumption and reduced maintenance requirements.
Long LED Life
Premium-quality LEDs provide an operational life of up to 50,000 hours, reducing the frequency of fixture replacement and supporting long-term lighting reliability.
High Power Quality
The luminaire provides a power factor greater than 0.95 and THD below 10%, supporting efficient and stable electrical performance.
Heavy-Duty Aluminium Construction
The rugged aluminium pressure die-cast housing provides structural strength while assisting heat dissipation from the LED and electrical components.
Weather Protection
With IP55/IP65 protection options, the luminaire is suitable for industrial environments and applications where protection against dust and moisture is required.
Electrical Protection
Surge protection exceeding 6 KVA and over-voltage protection up to 440V AC help safeguard the luminaire against electrical disturbances and unstable supply conditions.
High Colour Rendering
With CRI above 80, the LED Highbay Light provides a more natural colour appearance, supporting comfortable visibility in industrial and commercial working areas.
Made in India
The product is manufactured in India under stringent quality control procedures, providing customers with a dependable Made in India LED Highbay Light solution for industrial and commercial applications.
Choosing the right industrial lighting system can directly influence energy consumption, maintenance requirements, workplace visibility and overall operating costs. The LEEDAX 50 Watt LED Highbay Light is designed to provide a practical combination of illumination performance, energy efficiency and long-term reliability.
Energy Savings
The efficient 50W LED system converts electrical energy into useful illumination while minimizing unnecessary power consumption. This makes the product suitable for businesses looking to improve lighting efficiency and manage electricity costs.
Reduced Maintenance
With an LED life of up to 50,000 hours, the requirement for frequent lamp replacement is significantly reduced. This is particularly beneficial in warehouses, factories and other locations where replacing ceiling-mounted fixtures can require additional manpower and equipment.
Improved Workplace Visibility
The 120° beam angle and precision reflector design provide uniform light distribution with reduced dark spots. Better illumination can support improved visibility for production, storage, assembly and general workplace activities.
Reliable Long-Term Performance
The combination of premium LED components, an efficient driver, aluminium pressure die-cast housing and toughened glass provides a robust lighting solution for demanding environments.
Electrical Protection
Surge protection above 6 KVA, power factor greater than 0.95, THD below 10% and over-voltage protection up to 440V AC contribute to dependable electrical operation.
Lower Total Cost of Ownership
Reduced electricity consumption, long LED life and lower maintenance requirements can help reduce the overall operating cost of an industrial lighting installation over its service life.
Flexible Application
The availability of 3000K, 4000K and 6500K colour temperatures allows the product to address different lighting preferences and application requirements.
Durable Industrial Design
The aluminium die-cast construction supports effective thermal management and mechanical durability, making the LEEDAX 50W LED Highbay Light suitable for factories, warehouses, workshops and commercial facilities.
Factory-Direct Manufacturing
As a LED Highbay Light Manufacturer in India, LEEDAX offers factory-manufactured lighting solutions supported by controlled production and quality inspection processes.
The LEEDAX 50 Watt LED Highbay Light Luminary is designed for industrial, commercial, institutional and utility areas where efficient, uniform and dependable illumination is required. Its 50W configuration makes it particularly suitable for spaces where high-quality lighting is needed without unnecessarily high power consumption.
Industrial Applications
The 50W LED Highbay Light is suitable for small manufacturing units, workshops, assembly areas, production rooms, packaging units and machine shops. Its broad 120° illumination can help provide consistent visibility across working areas, supporting routine industrial operations.
Warehouse & Storage Applications
Warehouses and storage facilities require dependable lighting for movement, inventory handling and general visibility. The LEEDAX LED Highbay Light can be used in warehouses, godowns, inventory storage areas, logistics centres and distribution rooms, helping create a well-illuminated environment.
Commercial Applications
The luminaire can also be used in commercial spaces requiring efficient overhead lighting, including retail stores, shopping complexes, supermarkets, exhibition halls and commercial buildings. Its available colour temperatures provide flexibility for different commercial environments.
Institutional Applications
Educational and institutional facilities can use the 50W LED Highbay Light in educational institutions, laboratories, community halls and indoor sports areas, where dependable general illumination is required.
Utility & Service Areas
The product is also suitable for parking areas, service stations, industrial corridors, loading and unloading bays and utility rooms. Its durable construction and available IP protection make it appropriate for locations where dust, moisture or demanding operating conditions may be present.
Suitable Ceiling Heights
The luminaire is particularly suited to ceiling heights of approximately 4 to 7 metres, making it a practical choice for smaller industrial and commercial facilities.
Whether used for a new lighting installation or to replace conventional industrial lighting, the LEEDAX 50W LED Highbay Light provides an efficient and durable lighting solution for factories, warehouses, workshops, stores and commercial buildings.
